Name: Square Hydraulic Torque Wrench
Brand: HYTORC
Rating: 4.4 (31 reviews)

Avanti

The Avanti Hydraulic Torque Wrench presents an extensive spectrum of torque capabilities, featuring a remarkable peak output exceeding 130,000 ft-lbs in its largest model. With a global utilization count in the tens of thousands, the AVANTI stands as the established and relied-upon square torque wrench within the industry for advanced bolting solutions. The Avanti works with all HYTORC bolting systems

SPECIFICATIONS

Maximum Torque (Nm) / (ft-lbs)   187683 / 138510
Minimum Torque (Nm) / (ft-lbs)    3740 / 2760
Maximum Weight (kg) / (lbs)    265.91 / 585.00
Minimum Weight (kg) / (lbs) 21.68 / 47.7

PRODUCT CATALOGUE

ABS Hydraulic Torque Wrench - Avanti

MODEL

(inch/mm)

DRIVE

(inch)

WEIGHT

(lbs/kg)

TORQUE (ft-lbs/Nm)

MIN.

MAX.

AVANTI-20

10.22”

(260 mm)

5.07”

(129 mm)

10.94”

(278 mm)

2.60”

(66 mm)

2 1/2"

47.70 lbs (21.68 kg)

2,760 ft-lbs

(3,740 Nm)

17,890 ft-lbs

(24,241 Nm)

AVANTI-35

12.22”

(310 mm)

6.23”

(158 mm)

13.45”

(342 mm)

3.19”

(81 mm)

2 1/2"

82.75 lbs (37.61 kg)

4,905 ft-lbs

(6,646 Nm)

31,830 ft-lbs

(43,130 Nm)

AVANTI-50

13.90”

(353 mm)

7.04”

(179 mm)

15.54”

(395 mm)

3.95”

(100 mm)

2 1/2"

127.70 lbs (58.05 kg)

7,202 ft-lbs

(9,759 Nm)

46,126 ft-lbs

(62,501 Nm)

AVANTI-80

16.84”

(428 mm)

7.49”

(190 mm)

19.52”

(496 mm)

4.69”

(119 mm)

3 1/2"

280.50 lbs (127.50 kg)

11,965 ft-lbs

(16,213 Nm)

85,695 ft-lbs

(116,118 Nm)

AVANTI-130

19.40”

(493 mm)

8.50”

(216 mm)

22.73”

(577 mm)

5.31”

(135 mm)

3 1/2"

585.00 lbs (265.91 kg)

19,395 ft-lbs

(26,280 Nm)

138,510 ft-lbs

(187,683 Nm)

The Avanti stands out as the largest HYTORC tool, packing a powerful punch with torque sizes exceeding 138,000 ft.-lbs. Trusted by industry professionals for over two decades, the Avanti hydraulic torque wrench has a solid track record of proven performance.

Key Features:

1. Innovative Design: HYTORC's patented Reaction Drive, an industry-first, shields against damage from twisting forces when utilizing a back-end reaction arm. This design innovation ensures durability and reliability in the hydraulic torque tool.

2. Clear Angle Reading: Users benefit from a clear angle reading for each application during all bolting sessions, incorporating the Turn-of-the-Nut method. This feature enhances precision in torque application.

3. Compatibility: The Avanti is compatible with conventional bolting methods, as well as HYTORC Nut and HYTORC Washer systems, offering versatility for various bolting projects.

Key Advantages:

- Scale: Tailored for the most extensive applications and significant bolting projects in any industry.

- Versatile: Works seamlessly with all HYTORC bolting products and systems, ensuring ease of use for bolting professionals of all levels.

- Powerful Output: With a maximum output of over 138,000 ft.-lbs. in its largest model, the Avanti boasts one of the broadest torque ranges among all HYTORC tools.

The Avanti is not just a hydraulic wrench; it's a reliable companion for substantial bolting endeavors, delivering power, versatility, and a track record of dependable performance.

When considering your equipment investment, it's essential to explore the hydraulic torque wrench price to ensure a cost-effective solution without compromising quality.
Reach out to us via mail: lead@absgroup.in or call +91-8282 829 795.

Edge S

For tasks involving high torque requirements and consistent outcomes in routine maintenance, the EDGE S stands as the stalwart of HYTORC's square drive torque wrenches. Developed by HYTORC over three decades ago, its uncomplicated design comprising merely three moving components has undergone continuous refinements, yielding the most established and proven range of hydraulic torque wrenches globally.

SPECIFICATIONS

Maximum Torque (Nm) / (ft-lbs)   40176 / 29650
Minimum Torque (Nm) / (ft-lbs)    241 / 178
Maximum Weight (kg) / (lbs)    29.41 / 64.70
Minimum Weight (kg) / (lbs) 1.84 / 4.05

PRODUCT CATALOGUE

ABS Hydraulic Torque Wrench - Edge S

MODEL

(inch/mm)

DRIVE

(inch)

WEIGHT

(lbs/kg)

TORQUE (ft-lbs/Nm)

MIN.

MAX.

EDGE-1S

3.53"

(90 mm)

1.97"

(50 mm)

4.94"

(125 mm)

0.97"

(25 mm)

3/4"

4.05 lbs (1.84 kg)

178 ft-lbs

(241 Nm)

1257 ft-lbs

(1,703 Nm)

EDGE-3S

4.71"

(120 mm)

2.63"

(67 mm)

6.40"

(163 mm)

1.31"

(33 mm)

8.50 lbs (3.86 kg)

443 ft-lbs

(600 Nm)

3097 ft-lbs

(4,172 Nm)

EDGE-6S

6.04"

(153 mm)

3.18"

(81 mm)

7.61"

(193 mm)

1.57"

(40 mm)

1 1/2"

19.20 lbs (8.73 kg)

893 ft-lbs

(1,210 Nm)

6241 ft-lbs

(8,457 Nm)

EDGE-9S

6.58"

(167 mm)

3.57"

(91 mm)

8.69"

(221 mm)

1.86"

(47 mm)

1 1/2"

20.05 lbs (9.11 kg)

1230 ft-lbs

(1,667 Nm)

8555 ft-lbs

(11,592 Nm)

EDGE-11S

7.07"

(180 mm)

3.95"

(100 mm)

9.60"

(244 mm)

1.96"

(50 mm)

1 1/2"

25.00 lbs (11.36 kg)

1615 ft-lbs

(2,188 Nm)

11291 ft-lbs

(15,299 Nm)

EDGE-30S

10.10"

(257 mm)

5.64"

(143 mm)

13.71"

(348 mm)

2.79"

(71 mm)

2 1/2"

64.70 lbs (29.41 kg)

4448 ft-lbs

(6,027 Nm)

29650 ft-lbs

(40,176 Nm)

EDGE S Hydraulic Torque Wrench – Your Industrial Workhorse

Designed for robust performance in general maintenance demanding high torque values and consistent results, the EDGE S is a powerhouse. This industrial torque tool features a straightforward three-moving-part design, a testament to HYTORC's expertise over 30 years, consistently enhanced to create the most reliable line of hydraulic torque wrenches worldwide.

Key Specifications:
- Tool Type: Hydraulic Wrench
- Radius: 1.31" - 4.05"
- Weight: 8.50 - 64.70 lbs.
- Torque Range: 178.00 - 29650.00 ft-lbs.

User-Friendly Features:

1. Simple Operation:
The three-moving part design of the EDGE S series minimizes potential repairs, ensuring cost-effective and efficient operation.

2. Multi-Axis Swivel:
All HYTORC hydraulic torque wrenches (excluding the ICE series) feature a multi-axis swivel, offering maximum positioning flexibility and safety.

3. Removable Square Drive:
The EDGE S series is equipped with a removable square drive, allowing quick and simple directional changes for maximum durability.

The EDGE S Hydraulic Torque Tool is your reliable companion for industrial applications. Experience the ease of use, durability, and precision that come with over three decades of HYTORC innovation.

MXT+

The MXT+ Hydraulic Torque Wrench seamlessly integrates the strengths of HYTORC's original MXT Wrench with cutting-edge technological advancements. These innovations encompass a coaxial reaction drive, an auto-release feature, and an updated cycle counter. Distinguishing itself as a unique offering, the MXT+ stands as the sole tool encompassing rear reaction, side reaction, and reaction-arm-free configurations.

SPECIFICATIONS

Maximum Torque (Nm) / (ft-lbs)   16468 / 12148
Minimum Torque (Nm) / (ft-lbs)    278 / 205
Maximum Weight (kg) / (lbs)    11.33 / 25.00
Minimum Weight (kg) / (lbs) 3.08 / 6.80

PRODUCT CATALOGUE

ABS Hydraulic Torque Wrench - MXT+

MODEL

(inch/mm)

DRIVE

(inch)

WEIGHT

(lbs/kg)

TORQUE (ft-lbs/Nm)

MIN.

MAX.

MXTP-01

6.38”

(162 mm)

2.18”

(55 mm)

5.17”

(131 mm)

2.60”

(30 mm)

3/4"

6.80 lbs (3.08 kg)

205 ft-lbs

(278 Nm)

1,359 ft-lbs

(1,843 Nm)

MXTP-03

6.90”

(175 mm)

2.90”

(74 mm)

6.66”

(169 mm)

1.50”

(38 mm)

7.59 lbs (3.44 kg)

464 ft-lbs

(629 Nm)

3,117 ft-lbs

(4,225 Nm)

MXTP-05

9.24”

(235 mm)

3.38”

(86 mm)

8.04”

(204 mm)

1.86”

(47 mm)

1 1/2"

18.50 lbs (8.39 kg)

812 ft-lbs

(1,101 Nm)

5,422 ft-lbs

(7,350 Nm)

MXTP-10

11.69”

(297 mm)

4.35”

(110 mm)

10.05”

(255 mm)

2.38”

(60 mm)

1 1/2"

25.00 lbs (11.33 kg)

1,831 ft-lbs

(2,482 Nm)

12,148 ft-lbs

(16,468 Nm)

The MXT+ hydraulic torque wrench has several features for being your ideal tool:

Versatile Configuration Options:
The MXT+ is unparalleled as the only hydraulic torque tool providing rear reaction, side reaction, and reaction-arm-free configurations. This flexibility caters to diverse application needs.

Durable Design:
Crafted with aircraft-grade aluminum, the MXT+ is built to withstand over 5,000 duty cycles at max torque, ensuring longevity and reliability in every application.

Embedded Cycle Counter:
The MXT+ features an embedded cycle counter to maintain peak performance, ensuring accurate and repeatable bolting results.

Convenient Auto-Release:
The integrated auto-release feature eliminates the need for manual lever flipping, streamlining the process for the operator to unlock the tool from the application effortlessly.

Three Tools in One:
Equipped with various reaction fixtures—ALCO Arm, Rear Reaction Arm, Coaxial Reaction Arm, Rotatable Reaction Arm, Extension Reaction Fixture—the MXT+ hydraulic wrench is a versatile powerhouse.

Award-Winning Innovation:
The MXT+ proudly secured the prestigious Spotlight on New Technology Award at the 2022 Offshore Technology Conference, marking its excellence in the industry.

Industry Recognition:
Our MXT+ hydraulic torque tool has received acclaim from the Offshore Technology Conference, affirming its position as a technology leading the industry into the future.

Hassle-Free Warranty for Peace of Mind:

Our no-questions-asked warranty ensures worry-free protection, offering a no-deductible plan to shield you from unexpected repair costs and downtime. Your peace of mind is our priority. Experience the convenience, reliability, and innovation embodied by the MXT+ hydraulic tool—an industry leader recognized for its excellence and versatility.
